Telehandler 500-Hour Service Procedure
Intermediate service - telehandler / telescopic handler (all makes)
Engine (additional to 250-hour)
Hydraulic System (additional to 250-hour)
Transmission / Drivetrain (additional to 250-hour)
Brakes (additional to 250-hour)
Steering (additional to 250-hour)
Wheels (additional to 250-hour)
Boom (additional to 250-hour)
Load Safety (additional to 250-hour)
Cab (additional to 250-hour)
How to use: download the PDF, print or complete digitally on any device.
- PDF format, ready to print or fill on screen
- Use as-is or customise to suit your operation
- Go digital in MapTrack for photos, reminders and audit trails
Or set it up in MapTrack
- Fill it in on a phone, attach photos to any check
- Automatic reports and audit trails
- The same checks as the PDF, ready to configure
Free trial. No credit card. Personal email accepted.
Don't just download it - use it live. Start a free workspace with this telehandler 500-hour service procedure already built, so your crew can run it from a phone.
Co-Founder & Commercial Director
Short answer
A telehandler 500-hour service procedure records the scheduled service due at that interval: applicable filters and fluids, brakes, steering, wheel nut torque, boom wear pads and chains, the load moment indicator test and other safety devices. A fitter uses it where the model's schedule sets a 500-hour service, including any calendar limits. Regulation 213 requires competent-person maintenance following the manufacturer's recommendations.
Checked against Model WHS Regulations as at 5 December 2025 (cited within as the Work Health and Safety Regulations 2011) on by the MapTrack templates team. How we check templates
Key takeaways
- The MapTrack telehandler 500-hour service procedure contains 14 checks across 9 sections. Sections covered: Engine (additional to 250-hour), Hydraulic System (additional to 250-hour), Transmission / Drivetrain (additional to 250-hour), Brakes (additional to 250-hour), Steering (additional to 250-hour), Wheels (additional to 250-hour), Boom (additional to 250-hour), Load Safety (additional to 250-hour), Cab (additional to 250-hour).
- Check the 500-hour interval against the model's schedule, since some tasks fall due by calendar time or other hours; regulation 213 requires following the manufacturer's recommendations.
- Test the load moment indicator or rated capacity limiter as the manufacturer specifies, and keep the machine out of use if it reads out of tolerance.
- Measure and record brake lining, boom slide pad wear and chain condition each time, so wear trends show before a failure.
- AS 10896.1:2019 superseded AS 1418.19-2007 for non-slewing telehandlers; slewing models fall under ISO 10896-2:2016.
- Regulation 219 requires lifting plant to be used within its safe working limits.
Enter your email below to download this telehandler 500-hour service procedure as a ready-to-use PDF.
Used by construction, mining and field service teams
What is a telehandler 500-hour service procedure?
A 500-hour service is the second tier (intermediate) of scheduled preventive maintenance for a telehandler. It is performed every 500 engine hours (or approximately every 8-12 weeks of full-time operation). The 500-hour service carries forward all 250-hour tasks (engine oil and filter change, grease points, fluid level checks, basic inspections) and adds more in-depth maintenance: replacing the fuel filter, replacing the outer air filter element, replacing the hydraulic return filter, checking transmission oil and filter, full brake inspection with pad/shoe measurement, adjusting the park brake, inspecting steering linkage, torquing wheel nuts, measuring boom slide pad wear, inspecting boom extension chains/cables, testing load moment indicator calibration, servicing the A/C system and taking a hydraulic oil sample for laboratory analysis. It is typically performed by a qualified mechanic or fitter and takes 3 to 4 hours.
The 500-hour service is the interval at which critical wear items are formally measured and recorded. Boom slide pad wear, brake pad thickness and steering linkage play are all quantified at this point, creating trend data that allows fleet managers to plan component replacements proactively rather than reacting to failures. Hydraulic oil sampling at this interval provides laboratory-grade contamination and wear metal data that cannot be obtained through visual inspection alone.
Learn more about maintenance and work orders in MapTrack.
Get the free template
Enter your email above to download the full telehandler 500-hour service procedure as a PDF.
Benefits of using this telehandler 500-hour service procedure
- Early fault detection: hydraulic oil sampling at 500 hours catches contamination, metal particles and moisture before they damage pumps and valves.
- Brake safety: measuring brake pad/shoe thickness at regular intervals prevents brake failure on slopes, loading docks and uneven terrain.
- Boom longevity: measuring boom slide pad wear and inspecting extension chains/cables prevents costly boom repairs and ensures safe lifting.
- Reduced breakdowns: replacing filters and checking transmission and steering components on schedule prevents performance degradation and unplanned downtime.
- Compliance: documented service records at each interval demonstrate that equipment is maintained to WHS standards.
- Resale value: a complete service history with documented 250, 500 and 1,000-hour services increases the machine's value at trade-in or auction.
- Predictive maintenance: hydraulic oil sampling and brake measurements at the 500-hour interval provide quantitative data for forecasting component replacements.
Benefits of digitising forms in MapTrack
When you digitise telehandler service procedures in MapTrack, you get:
- Field users can easily scan a QR code to complete a form on mobile. Unlimited users.
- Email the right people when a form is submitted, with an automation you set up.
- File every completed form against the asset, location or person it covers.
- Download any completed form as a PDF, with failed answers listed at the top.
- Fill in forms offline; they upload when the device is back online.
- Build conditional logic (show or hide questions based on answers).
- Take pictures or attach photos. Not possible with a paper-based form.
- Electronic signatures.
- Edit forms later without reprinting.
- Set who can view, fill in or edit forms with user roles.
- Upload a paper form (PDF, Word, Excel or a photo) and MapTrack's AI builds a digital version for you to check.
- Raise a work order from a submitted form with an automation you set up.
- Track service intervals by hours, kilometres or calendar date in one place.
- Attach supplier invoices and parts receipts to each maintenance record.
Book a demo to see how MapTrack handles telehandler service procedures.
Try MapTrack free
Full access to every feature. No credit card required. Per-asset pricing so you scale as your fleet grows.
- No credit card required
1-2 days/week saved
“Bloody amazing! We used to spend 1-2 days a week tracking and managing our generators alone.”
Steve McAllister
Asset Coordinator, Saunders International
What to include in a telehandler 500-hour service procedure
This telehandler 500-hour service procedure covers 9 key areas:
- Engine: replace fuel filter, replace outer air filter element.
- Hydraulic system: replace hydraulic return filter, take hydraulic oil sample for laboratory analysis.
- Transmission / drivetrain: check transmission oil level and condition (replace filter if separate), inspect axle oil levels (front and rear).
- Brakes: full brake inspection measuring pad/shoe thickness front and rear, adjust park brake.
- Steering: inspect steering linkage (ball joints, tie rods, drag link).
- Wheels: torque wheel nuts to spec.
- Boom: check boom slide pad wear (measure), inspect boom extension chains/cables (if fitted).
- Load safety: test load moment indicator calibration.
- Cab: service A/C system (check refrigerant, clean condenser).
How to use this telehandler 500-hour service procedure
- Complete the full 250-hour service procedure first (engine oil and filter change, grease points, fluid level checks, basic inspections, safety device testing). Use the 250-hour service checklist .: Perform the entire 250-hour checklist including engine oil and filter change, all grease points, hydraulic level check, boom function test, tyre checks, lights, safety devices and sign-off before starting 500-hour-specific tasks.
- Replace the fuel filter. Drain any trapped fuel from the filter housing before fitting the new element.: Place a drip tray below the filter housing before removal. Drain residual fuel from the housing, clean the sealing surfaces and fit the new element dry. Prime the fuel system by operating the hand pump or cranking until fuel pressure stabilises.
- Replace the outer air filter element. Inspect the inner element and replace only if visibly damaged or due at 1,000 hours.: Remove the outer element carefully to prevent debris falling into the intake housing. Clean the housing with a damp cloth. The inner safety element protects the engine if the outer element fails and should only be replaced when damaged, not cleaned.
- Replace the hydraulic return filter. Before installing the new filter, take a hydraulic oil sample from the return line for laboratory analysis.: Draw the oil sample from the designated sample port while the oil is at operating temperature. Use a clean sample bottle and label it with the machine ID, current hours and date. Send the sample to a certified oil analysis laboratory for particle count, viscosity and wear metal analysis.
- Check transmission oil level and condition. Replace the transmission filter if your model has a separate filter.: Check the transmission dipstick with the oil at operating temperature and the engine idling in neutral. Note the oil colour and smell. Dark or burnt-smelling transmission oil indicates overheating or clutch wear and should be scheduled for replacement.
- Inspect axle oil levels on both front and rear axles. Top up if low.: Remove the fill/level plug on each axle and verify oil is at the correct level. Top up with the manufacturer-specified axle oil (commonly 80W-90 or 85W-140 gear oil). Note any metallic sheen or contamination that may indicate internal wear.
- Perform a full brake inspection: measure brake pad/shoe thickness on front and rear axles. Adjust the park brake to the manufacturer's specification.: Measure brake pad or shoe thickness at all wheel positions and record in millimetres. Compare against the manufacturer minimum service limit. Adjust the park brake mechanism to ensure it holds the machine on a slope equivalent to the maximum rated operating grade.
- Inspect steering linkage: check ball joints, tie rods and drag link for wear and play.: With the engine off, rock the front wheels side to side and check for play in ball joints, tie rod ends and the drag link. Any noticeable movement beyond the manufacturer tolerance indicates a component that should be replaced before the next service.
- Torque all wheel nuts to the manufacturer's specification.: Use a calibrated torque wrench and tighten wheel nuts in a star pattern to the specification listed in the service manual. Typical telehandler wheel nut torque is 450 to 600 Nm depending on the stud size.
- Measure boom slide pad wear and record for trend comparison. Inspect boom extension chains or cables (if fitted) for stretch and damage.: Measure the thickness of each boom slide pad and wear strip and compare against the minimum specification. Record the measurements for trend analysis across service intervals. Inspect extension chains for elongation beyond the OEM limit or damaged links, and cables for broken strands.
- Test the load moment indicator calibration to confirm it reads accurately.: Use a known test weight at a known boom angle and extension to verify the load moment indicator displays the correct load. If the reading is outside tolerance, arrange for recalibration by a qualified technician before the machine returns to service.
- Service the A/C system: check refrigerant level and clean the condenser.: Check the A/C system for correct cooling performance. Inspect the condenser for blocked fins and clean with low-pressure compressed air. If cooling performance is poor, check refrigerant charge and inspect for leaks at hose connections and the compressor seal.
- Start the engine and check for leaks, abnormal noises or warning lights. Record any defects or recommendations in the notes section. Set the next service due hours and sign off.: Run the engine for at least five minutes and operate all hydraulic functions and the boom through full travel. Walk around the machine checking for fluid leaks. Record all findings, measurements and follow-up items in the service form. Update the next service due hours and sign off.
In MapTrack, you can schedule and track maintenance digitally, by date or meter reading. Each submission is stored as a timestamped PDF against the asset record.
Get the free templateEnter your email above to download the full telehandler 500-hour service procedure as a PDF.Back to download formHow often should you complete this service procedure?
Telehandlers should receive a 500-hour intermediate service every 500 engine hours, which typically falls every 8 to 12 weeks on a full-time construction site. This service carries forward all 250-hour tasks and adds hydraulic filter replacement, fuel filter replacement, brake inspection, boom slide pad measurement, steering linkage check, wheel nut torque, load moment indicator test and hydraulic oil sampling.
The 500-hour interval should not be deferred, as worn brake pads, degraded hydraulic oil and stretched boom chains can all create safety hazards. Telehandlers used on high-cycle sites such as precast panel erection or bulk materials handling may require shortened intervals. Always follow the manufacturer service manual.
Try MapTrack free
Full access to every feature. No credit card required. Per-asset pricing so you scale as your fleet grows.
- No credit card required
Frequently asked questions
Applicable regulatory standards
This template is a starting point. Check the current requirements that apply to your equipment, work and location. The template alone does not establish compliance.
| Standard | Edition | Clauses this template relies on | Source |
|---|---|---|---|
| Model Work Health and Safety RegulationsCompetent-person maintenance per the manufacturer, and lifting plant used within its safe working limits. | Model WHS Regulations as at 5 December 2025 (cited within as the Work Health and Safety Regulations 2011) |
| Safe Work Australia (drafted by the Parliamentary Counsel's Committee) |
| Rough-terrain trucks - Safety requirements and verification, Part 1: Variable-reach trucks (ISO 10896-1:2012, MOD)Safety requirements for non-slewing variable-reach trucks; it superseded AS 1418.19-2007. | AS 10896.1:2019 | Whole instrument | Standards AustraliaSold by the publisher |
| Rough-terrain trucks - Safety requirements and verification - Part 2: Slewing trucksSafety requirements for slewing rough-terrain trucks, the rotating telehandlers. | ISO 10896-2:2016 (Edition 1) | Whole instrument | International Organization for Standardization (ISO)Sold by the publisher |
| Model Code of Practice: Managing risks of plant in the workplaceMaintenance by competent people per the manufacturer's instructions, and isolating energy before the work. | November 2024 version (reviewed May 2018; amended 2021, 2023 and 2024) |
| Safe Work Australia |
Model Work Health and Safety Regulations
Edition: Model WHS Regulations as at 5 December 2025 (cited within as the Work Health and Safety Regulations 2011)
Competent-person maintenance per the manufacturer, and lifting plant used within its safe working limits.
- reg 213: Plant must be maintained, inspected and, if necessary, tested by a competent person, following manufacturer or competent person recommendations; annual inspection applies only if neither is practicable.
- reg 219: Lifting plant must be designed for the load so far as reasonably practicable, with safeguards for alternatives, suitable lifting attachments, and use within safe working limits.
Safe Work Australia (drafted by the Parliamentary Counsel's Committee)
Rough-terrain trucks - Safety requirements and verification, Part 1: Variable-reach trucks (ISO 10896-1:2012, MOD)
Edition: AS 10896.1:2019
Safety requirements for non-slewing variable-reach trucks; it superseded AS 1418.19-2007.
Standards AustraliaSold by the publisher
Rough-terrain trucks - Safety requirements and verification - Part 2: Slewing trucks
Edition: ISO 10896-2:2016 (Edition 1)
Safety requirements for slewing rough-terrain trucks, the rotating telehandlers.
International Organization for Standardization (ISO)Sold by the publisher
Model Code of Practice: Managing risks of plant in the workplace
Edition: November 2024 version (reviewed May 2018; amended 2021, 2023 and 2024)
Maintenance by competent people per the manufacturer's instructions, and isolating energy before the work.
- Section 3.6: Maintenance, repair and cleaning of plant, following manufacturer instructions and by competent people.
- Section 4.5: Isolating energy sources before maintenance, repair or cleaning, with lock-out as the most effective isolation procedure.
Each source was read at its publisher and the page checked on 26 October 2026. The publisher's current text is the authority.
