Air Compressor 250-Hour Service Procedure
Minor service - portable diesel air compressor (all makes)
Engine
Compressor System
Lubrication
Controls and Gauges
Structural / Safety
How to use: download the PDF, print or complete digitally on any device.
- PDF format, ready to print or fill on screen
- Use as-is or customise to suit your operation
- Go digital in MapTrack for photos, reminders and audit trails
Don't just download it - use it live. Start a free workspace with this air compressor 250-hour service procedure already built, so your crew can run it from a phone.
Co-Founder & Commercial Director
Short answer
An air compressor 250-hour service procedure records the minor service on a portable diesel compressor: engine oil and filter, air filter, fuel and receiver drains, safety relief valve, belts, hoses, gauges, structure and emergency stop. Fitters do it every 250 engine hours or as the manufacturer sets. Regulation 224 of the model WHS Regulations requires pressure equipment, such as the receiver, to be inspected regularly by a competent person.
Checked against Model WHS Regulations as at 5 December 2025 (cited within as the Work Health and Safety Regulations 2011) on by the MapTrack templates team. How we check templates
Key takeaways
- The MapTrack air compressor 250-hour service procedure contains 16 checks across 5 sections. Sections covered: Engine, Compressor System, Lubrication, Controls and Gauges, Structural / Safety.
- Regulation 224 requires the receiver to be inspected regularly by a competent person; AS/NZS 3788 clauses 4.4 and 4.5 cover how intervals are set.
- This template uses a 250-hour planning interval; set each task from the compressor manufacturer's schedule, which regulation 213 puts first.
- Check Schedule 5 of the model WHS Regulations to see whether the receiver's design or the item itself must be registered.
- A safety relief valve that fails its check is a fail: the compressor stays out of service until the valve is replaced.
- Keep a history record for the receiver (AS/NZS 3788 clause 8.6) with each inspection and relief valve result.
Enter your email below to download this air compressor 250-hour service procedure as a ready-to-use PDF.
Used by construction, mining and field service teams
What is an air compressor 250-hour service procedure?
A 250-hour service is the first tier of scheduled preventive maintenance for a portable diesel air compressor. It is performed every 250 engine hours and is classified as a minor service. The procedure covers engine oil and filter replacement, air filter inspection, fuel/water separator drain, receiver tank condensate drain, safety relief valve testing, compressor oil level check (rotary screw) or valve condition check (reciprocating), belt tension and condition, air hose and coupling inspection, aftercooler check, grease points, pressure gauge and regulator checks, pressure switch testing, structural inspection (wheels, frame, tow bar), earthing lead check and emergency stop testing. Unlike a daily pre-start check (which confirms the compressor is safe to operate), the 250-hour service involves actual maintenance actions: draining and replacing fluids, replacing filters and testing safety devices. It is typically performed by a qualified mechanic or fitter, not the operator.
From an operational standpoint, the 250-hour service is critical for maintaining uptime on construction sites, mining operations and industrial facilities where compressed air powers pneumatic tools, sandblasting equipment and breathing air systems. In Australia, the receiver tank on a portable air compressor is pressure equipment under the WHS Regulations 2011: Part 5.1 requires it to be inspected regularly by a competent person (regulation 224), and whether it must be registered depends on its hazard level. The design of pressure equipment at hazard level A to D must be registered, and a pressure vessel at hazard level A, B or C must itself be registered unless it is serially produced (Part 5.3 and Schedule 5). AS/NZS 3788 covers its in-service inspection. Failure to perform scheduled servicing can lead to equipment registration lapses, rejected insurance claims and, in the worst case, pressure vessel failure caused by corrosion or seized safety valves. Maintaining a documented 250-hour service history also supports resale value and provides auditable evidence of compliance during workplace safety inspections.
Learn more about maintenance and work orders in MapTrack.
Get the free template
Enter your email above to download the full air compressor 250-hour service procedure as a PDF.
Benefits of using this air compressor 250-hour service procedure
- Reduced breakdowns: regular oil, filter and fluid changes prevent engine and compressor failures that cause unplanned downtime on site.
- Extended component life: clean oil and correct lubrication reduce wear on engine, compressor element, valves and drive belts.
- Lower repair costs: a 250-hour service costs a fraction of an emergency breakdown repair. Catching issues early prevents cascading damage.
- Operator safety: testing safety relief valves, emergency stops and inspecting air hoses at regular intervals reduces the risk of on-site incidents.
- Compliance: documented service records demonstrate that pressure equipment is maintained to WHS and Australian Standards, supporting insurance and regulatory obligations.
- Resale value: a complete service history with documented 250 and 500-hour services increases the compressor's value at trade-in or sale.
Benefits of digitising forms in MapTrack
When you digitise air compressor service procedures in MapTrack, you get:
- Field users can easily scan a QR code to complete a form on mobile. Unlimited users.
- Email the right people when a form is submitted, with an automation you set up.
- File every completed form against the asset, location or person it covers.
- Download any completed form as a PDF, with failed answers listed at the top.
- Fill in forms offline; they upload when the device is back online.
- Build conditional logic (show or hide questions based on answers).
- Take pictures or attach photos. Not possible with a paper-based form.
- Electronic signatures.
- Edit forms later without reprinting.
- Set who can view, fill in or edit forms with user roles.
- Upload a paper form (PDF, Word, Excel or a photo) and MapTrack's AI builds a digital version for you to check.
- Raise a work order from a submitted form with an automation you set up.
- Track service intervals by hours, kilometres or calendar date in one place.
- Attach supplier invoices and parts receipts to each maintenance record.
Book a demo to see how MapTrack handles air compressor service procedures.
Try MapTrack free
Full access to every feature. No credit card required. Per-asset pricing so you scale as your fleet grows.
- No credit card required
1-2 days/week saved
“Bloody amazing! We used to spend 1-2 days a week tracking and managing our generators alone.”
Steve McAllister
Asset Coordinator, Saunders International
What to include in an air compressor 250-hour service procedure
This air compressor 250-hour service procedure covers 5 key areas:
- Engine: drain and replace engine oil (15W-40), replace oil filter, inspect air filter element, drain fuel/water separator.
- Compressor system: check and drain receiver tank condensate, test safety relief valve, inspect compressor oil level or valve condition, check belt tension, inspect air hoses, couplings and whip checks, check oil/water separator.
- Lubrication: grease all specified grease points.
- Controls and gauges: check pressure gauges and regulator, test pressure switch cut-in/cut-out.
- Structural / safety: inspect wheels, frame and tow bar, check earthing lead, test emergency stop.
How to use this air compressor 250-hour service procedure
- Shut down the compressor and allow it to depressurise fully. Isolate the engine and allow it to cool before draining oil.: Wait until the receiver tank gauge reads zero pressure. Open the manual drain valve to confirm depressurisation. Allow the engine to cool for at least 15 minutes before removing the oil drain plug.
- Record the equipment details and current hour meter reading at the top of the service procedure form.: Capture the asset ID, make, model, serial number, site location and the current engine hour meter reading. Cross-reference the reading against the previous service to confirm the correct interval has elapsed.
- Start with the engine section: drain the old engine oil, replace the oil filter, fill with new oil to the correct level, then inspect the air filter and drain the fuel/water separator.: Use 15W-40 CI-4 or CK-4 diesel engine oil. Fill to the full mark on the dipstick (typically 6-12 litres). Check the air filter element for blockage or damage and replace if dirty. Drain the fuel/water separator bowl completely.
- Move to the compressor system: drain receiver tank condensate, test the safety relief valve, check compressor oil level (rotary screw) or valve condition (reciprocating), inspect belt tension and condition, inspect air hoses and couplings, and check the aftercooler.: Open the receiver tank drain and release all accumulated condensate. Lift the safety relief valve lever to confirm it opens freely and reseats. Check belt deflection is within 10-15 mm at the midpoint. Inspect all hoses for cracking, bulging or worn couplings.
- Grease all specified grease points using EP2 lithium complex grease.: Apply two to three pumps of EP2 grease at each nipple until fresh grease appears at the seal. Cover all tow bar pivot points, axle bearings and any hinged access panel pivot points specified by the manufacturer.
- Check pressure gauges and the regulator. Test the pressure switch cut-in and cut-out operation.: Compare the gauge reading against a calibrated reference gauge if available. Adjust the regulator to the rated working pressure. Verify the pressure switch cuts in and out within the manufacturer tolerance, typically within 5 psi of the set point.
- Inspect wheels, frame and tow bar. Check the earthing lead. Test the emergency stop.: Check tyre inflation and tread condition on portable units. Inspect the tow bar coupling pin and safety chain for wear. Confirm the earthing lead clamp is intact and the cable is undamaged. Press the emergency stop and confirm the engine shuts down immediately.
- Start the compressor and check for leaks, abnormal noises or warning lights. Verify operating pressure reaches the correct set point. Record any defects or recommendations in the notes section.: Run the compressor for at least five minutes and listen for unusual knocking, squealing or vibration. Spray soapy water on fittings to check for air leaks. Confirm the operating pressure stabilises at the rated set point and the safety relief valve does not weep.
- Set the next service due hours (next 250-hour and next 500-hour intervals). Sign off and update the machine's maintenance log.: Calculate the next service due hours by adding 250 and 500 to the current reading. Update the service sticker on the machine and record the completed service in the central maintenance system or log book.
In MapTrack, you can schedule and track maintenance digitally, by date or meter reading. Each submission is stored as a timestamped PDF against the asset record.
Get the free templateEnter your email above to download the full air compressor 250-hour service procedure as a PDF.Back to download formHow often should you complete this service procedure?
Portable diesel air compressors should receive a 250-hour minor service every 250 engine hours, which equates to roughly every four to six weeks of full-time site use. A 500-hour major service is due every 500 engine hours or annually, whichever comes first. Between scheduled services, operators should perform a daily pre-start check before each use, covering oil level, condensate drain, hose condition, safety valve and emergency stop.
On high-utilisation sites where compressors run continuously, the 250-hour interval may arrive within three weeks. In such cases, do not defer the service, as engine oil degrades faster under sustained load. Conversely, compressors that sit idle for extended periods should still receive a service at least every six months to prevent corrosion and stale fuel issues. Always follow the manufacturer service manual for your specific make and model.
Try MapTrack free
Full access to every feature. No credit card required. Per-asset pricing so you scale as your fleet grows.
- No credit card required
Frequently asked questions
Applicable regulatory standards
This template is a starting point. Check the current requirements that apply to your equipment, work and location. The template alone does not establish compliance.
| Standard | Edition | Clauses this template relies on | Source |
|---|---|---|---|
| Model Work Health and Safety RegulationsRegular competent-person inspection of the receiver, maintenance following the manufacturer, and which pressure equipment must be registered. | Model WHS Regulations as at 5 December 2025 (cited within as the Work Health and Safety Regulations 2011) |
| Safe Work Australia (drafted by the Parliamentary Counsel's Committee) |
| Pressure equipment - In-service inspectionIn-service inspection of the receiver: time-based or risk-based intervals, pressure-relief devices, and the history record for each vessel. | AS/NZS 3788:2024 (incl. Amd 1:2025) |
| Standards Australia and Standards New ZealandSold by the publisher |
| Pressure vesselsDesign and construction of pressure vessels such as the receiver tank (2010 edition, reconfirmed 2021). | AS 1210-2010 (incl. Amd 1 and Amd 2:2015) | Whole instrument | Standards AustraliaSold by the publisher |
Model Work Health and Safety Regulations
Edition: Model WHS Regulations as at 5 December 2025 (cited within as the Work Health and Safety Regulations 2011)
Regular competent-person inspection of the receiver, maintenance following the manufacturer, and which pressure equipment must be registered.
- reg 224: Pressure equipment must be inspected regularly by a competent person; inspected gas cylinders carry a current inspection mark.
- reg 213: Plant must be maintained, inspected and, if necessary, tested by a competent person, following manufacturer or competent person recommendations; annual inspection applies only if neither is practicable.
- Part 5.3: Registration of plant designs and items of plant with the regulator.
- Schedule 5: Plant requiring registration: plant designs (Part 1) and items of plant (Part 2), such as boilers and tower cranes.
Safe Work Australia (drafted by the Parliamentary Counsel's Committee)
Pressure equipment - In-service inspection
Edition: AS/NZS 3788:2024 (incl. Amd 1:2025)
In-service inspection of the receiver: time-based or risk-based intervals, pressure-relief devices, and the history record for each vessel.
- 4.4: Time-based intervals between pressure equipment inspections
- 4.5: Risk-based inspection as an alternative basis for intervals
- 4.6: Inspection of pressure-relief devices
- 8.6: Keeping a history record for each item of pressure equipment
Standards Australia and Standards New ZealandSold by the publisher
Pressure vessels
Edition: AS 1210-2010 (incl. Amd 1 and Amd 2:2015)
Design and construction of pressure vessels such as the receiver tank (2010 edition, reconfirmed 2021).
Standards AustraliaSold by the publisher
Each source was read at its publisher and the page checked on 26 October 2026. The publisher's current text is the authority.
